9FP-30H12-Fuse, 12A, 1500Vdc, Type gPV Photovoltaic, 10x85mm
Regular price
$12.74 CAD
Couldn't load pickup availability
DUTY NOTICE!
For international shipping to outside of Canada, all price listed doesn't not inlcude duties. it is customer's responsibility to pay all associated duties.
| Primary brand | NOARK |
| Main function | Fuse |
| Product series / family name | Electrical protection > Fuse protections > Fuses for photovoltaic applications |
| Sub-range name | 9FP series |
| Functions | Photovoltaic fuse |
| Design | high-breaking capacity high-breaking capacity (UL248-19) |
| Short circuit breaking rating | 20kA |
| Dimensions | H85mm x W10.3mm x D10.3mm H3.35" x W0.41" x D0.41" |
| Order code / Manufacturer SKU | 9FP-30H12 1002554 |
| Manufacturer product status | Commercialized |
| Equivalent to | 1002554 9FP30H12 |
| Compliant with standard(s) | UL248-19 |
| Short Description | Photovoltaic fuse - 1002554 - 12A - 1500Vdc - high-breaking capacity - UL248-19 |
| Type | Option = Standard (No options) |
| Rated current | ``10A < In ≤ 15 12A |
| Rated Voltage (DC) | 1500Vdc |
| Net weight | 20 |
| Cross-sells with | 9FP30H |
| Category code | Global_Cat_001001008 Electrical components Electrical circuits protection Fuse protections |
| Product title | Photovoltaic fuse - NOARK 9FP series |
| Description generating formula | A |
| Description | Photovoltaic fuse - high-breaking capacity - high-breaking capacity (UL248-19) - NOARK (9FP series) - 12A rated current - 1500Vdc rated voltage - equivalent to 1002554 / 9FP30H12 |
| Catalogue connector | NOARK - Fuse-holders and fuses - 9FP series 9FP-30H12 |
