9FP-30H4-Fuse, 4A, 1500Vdc, Type gPV Photovoltaic, 10x85mm

In stock - 10 items available
SKU: 9FP-30H4
Regular price $12.74 CAD
Primary brand NOARK
Main function Fuse
Product series / family name Electrical protection > Fuse protections > Fuses for photovoltaic applications
Sub-range name 9FP series
Functions Photovoltaic fuse
Design high-breaking capacity
high-breaking capacity (UL248-19)
Short circuit breaking rating 20kA
Dimensions H85mm x W10.3mm x D10.3mm
H3.35" x W0.41" x D0.41"
Order code / Manufacturer SKU 9FP-30H4
1002550
Manufacturer product status Commercialized
Equivalent to 1002550
9FP30H4
Compliant with standard(s) UL248-19
Short Description Photovoltaic fuse - 1002550 - 4A - 1500Vdc - high-breaking capacity - UL248-19
Type Option = Standard (No options)
Rated current ```1A < In ≤ 5
4A
Rated Voltage (DC) 1500Vdc
Net weight 20
Cross-sells with 9FP30H
Category code Global_Cat_001001008
Electrical components
Electrical circuits protection
Fuse protections
Product title Photovoltaic fuse - NOARK 9FP series
Description generating formula A
Description Photovoltaic fuse - high-breaking capacity - high-breaking capacity (UL248-19) - NOARK (9FP series) - 4A rated current - 1500Vdc rated voltage - equivalent to 1002550 / 9FP30H4
Catalogue connector NOARK - Fuse-holders and fuses - 9FP series
9FP-30H4
