| Series | LK series |
| Dimensions | 30(L)*65(H)*46(W)mm |
| Rated current(I) | 80A IEC |
| Rated current(I) | 85A UL/CSA |
| IPK | 22KA |
| Icw | 3KA rms |
| Rated voltage(Ui) | 1000V IEC |
| Rated voltage(Ui) | 600V UL |
| Input(Metric) | 6...16 mm² X 1 |
| Output(Metric) | 2.5...6 mm² X 4 |
| 2.5...16 mm² X 2 | |
| Input(Imperial) | 16...4 AWG X 1 |
| Output(Imperial) | 16...8 AWG X 4 |
| 16...4 AWG X 2 | |
| Flame retardant rating as per UL94 | V0 |
| Contact material | Copper |
| Surface treatment | Tin-plated |
| Cover material | PA66 |
| Series | LK series |
