M3MS400T3L-UL489 Standard MCP, M3MS, 400 A Frame Size, 42kA@480Vac, 400A, 3P, Lug Line/Load Side
Regular price
$863.12 CAD
Couldn't load pickup availability
| Primary brand | NOARK |
| Main function | Motor Protection Circuit Breaker (MPCB) |
| Product series / family name | Electrical protection > Circuit breakers > Motor-Circuit Protectors (MCPs) |
| Sub-range name | Ex9M3M series |
| Functions | Magnetic-only Motor Circuit Protector (MCP) |
| Poles | 3-poles (3P3d) |
| Frame current rating | 400 |
| Rated operating voltage (Ue) | (IEC) 690 |
| Rated voltage (AC) | 600Vac (50/60Hz) |
| Rated impulse voltage (Uimp) | 8 |
| Rated insulation voltage (Ui) | 800 |
| Connection type | Lugs on both load and line sides |
| Short circuit breaking rating | 65kA (240Vac) 42kA (480Vac) 18kA (600Vac) |
| Ultimate short circuit current breaking capacity (Icu) | 65kA (220/240Vac) 65kA (380/415Vac) 10kA (660/690Vac) |
| Trip unit type | ```Technology = Thermal-Magnetic (adjustable) |
| Protection functions | Adjustable thermal protection (Overload) Adjustable threshold Magnetic protection (Short-circuit) |
| Protection settings | Protection against thermal overload -- adjustable FLA to 7 pre-defined settings (153.8A...184.5A / 184.6A...215.3A / 215.4A...246A / 246.1A...276.8A / 276.9A...307.6A / 307.7A...338.4A / 338.5A...348.1A) Magnetic instantaneous protection against short-circuit -- adjustable to 7 pre-defined settings (2000A / 2400A / 2800A / 3200A / 3600A / 4000A / 4400A) |
| Dimensions | H285mm x W140mm x D116.5mm H11.22" x W5.51" x D4.59" |
| Order code / Manufacturer SKU | M3MS400T3L 1101491 |
| Manufacturer product status | Commercialized |
| Equivalent to | 1101491 |
| Compliant with standard(s) | UL489 listed UL489 recognized (file number E355392) CSA C22.2 No.5 IEC/EN 60947-2 CE compliant RoHS compliant |
| Electrical durability | 5000 hours |
| Mechanical durability | 8000 hours |
| Short Description | Magnetic-only MCP - 1101491 - UL489 - M3 frame - 3P3d - 400A rated - 600Vac |
| Type | Option = Standard (No options) |
| Rated current | 400A (continuous Amperes) |
| Connection type(electrical) | Fixed Lug connection |
| Net weight | 6100 |
| Cross - sells with | AL/AX21P SHT22NA SHT22NB SHT22NC SHT22ND SHT22NE SHT22NGWS UVT22NA UVT22NB UVT22NC UVT22ND UVT22NE UVT22NF UVT22NG UVT22NH KLK23NA KLK23NB KLK23NC MIT23NA MOD23NA MOD23NB MOD23NC FH4XC FH4XD OMC OMB23 FSB10 NOARK-FSB2 FSB3 FSB4 FSB5 FSB6 FSB7 NOARK-FSB8 FSB9 LTC23NAA LTC23NBA LTC23NCA LTC23NEA LTC23NFA LK23NBA LK23NCA LK23NEA LK23NFA RCP23N TC23N TC23NB PIA23N |
| Category code | Global_Cat_001001001004 Electrical components Electrical circuits protection Circuit Breakers (CB) Motor Protection Circuit Breakers (MPCB) |
| Product title | Magnetic-only Motor Circuit Protector (MCP) - NOARK Ex9M3M series |
| Description generating formula | A |
| Description | Magnetic-only Motor Circuit Protector (MCP) - UL489 listed - NOARK (Ex9M3M series) - 3-poles (3P3d) - Rated current 400A (continuous Amperes) - Interrupting capacity 18kA (600Vac) - Lugs on both load and line sides - Thermal-Magnetic (adjustable) trip unit - equivalent to 1101491 |
