XF11NDF-ACB Closing release, For 2500A Frame (A25) ACB, Fixed type, Control voltage 200-240Vac/dc
Regular price
$425.38 CAD
Couldn't load pickup availability
| Primary brand | NOARK |
| Main function | Coil (closing) |
| Product series / family name | Electrical protection > ACBs and disconnector switches accessories > Auxiliary controls |
| Sub-range name | A25 series |
| Functions | Closing release coil |
| Order code / Manufacturer SKU | XF11NDF 1800966 |
| Manufacturer product status | Commercialized |
| Equivalent to | 1800966 |
| Technical compatibility with | for A25/ASD25 (2500A) frame size |
| Short Description | Closing release coil - 1800966 - 2500A frame - for A25/ASD25 (2500A) ACB/switch disconnector |
| Type | Option = Standard (No options) |
| Power consumption | (inrush) 500 (continuous) 4.5 (inrush) 500 (continuous) 4.5 |
| Response time | (operating time) max. 50ms / 0.05 |
| Category code | Global_Cat_001001 Electrical components Electrical circuits protection |
| Product title | Closing release coil - NOARK A25 series |
| Description generating formula | A |
| Description | Closing release coil - for A25/ASD25 (2500A) frame size - NOARK (A25 series) - 146-264Vdc (200Vdc-240Vdc nom.) / 146-264Vac (200Vac-240Vac nom.) control voltage - equivalent to 1800966 |
| Catalogue connector | NOARK - A25 ASD25 accessories XF11NDF |
